Furnace CCTV



FurnaceSpection Furnace Inspection System for Continuous Temperature Measurement Inside Furnaces



The FurnaceSpection furnace inspection system is a radiometrically calibrated thermal imaging system that provides real-time continuous temperature measurement inside high-temperature furnaces in refining, metals, and glass production processes. It measures the temperature of product, refractory, and heat transfer surfaces inside natural gas-fired furnaces. The powerful software enables process abnormalities to be quickly identified before they develop into problems, with streaming images, historical trending, digital and analogue outputs. The system can be configured for use with either single or multiple camera configurations.

Key features
Accurate 640 x 480 focal-plane array thermal imaging camera with a sensitivity of 0.06°C
Boroscope optics filtered at 0.85 μm wavelength to view through combustion gas and flames
Rugged IP66 air or water-cooled (SD), stainless steel protective enclosure
Standard (SD) with auto-retraction and Mobile (MB) versions available
Radiometrically calibrated



Client: 650MW Coal Fired Power Plant

Model:HTO-70 With Extraction Bench/Local Display
